DIN333A HSS Center Drills With Milled & Fully Ground Flute

Products

DIN333A HSS Center Drills With Milled & Fully Ground Flute Featured Image
  • DIN333A HSS Center Drills With Milled & Fully Ground Flute
  • DIN333A HSS Center Drills With Milled & Fully Ground Flute
  • DIN333A HSS Center Drills With Milled & Fully Ground Flute
  • DIN333A HSS Center Drills With Milled & Fully Ground Flute

DIN333A HSS Center Drills With Milled & Fully Ground Flute

product_icons_img
product_icons_img
product_icons_img
product_icons_img
product_icons_img

We warmly welcome you to explore our website and discover the center drill.
We’re delighted to offer you complimentary samples for testing of center drill, and we’re here to provide you with OEM, OBM, and ODM services.

Below are the product specifications for :
● Durable HSS material

● Accurate tip angle

● Versatile use

● Various sizes

● Long lifespan

If you have any questions or would like to inquire about pricing, please don’t hesitate to reach out to us.

WhatsApp Email

Specification

Application

Advantage

Matching Items

Solution

Packing

HSS Center Drills

● Material: HSS
● Right hand cutting.
● Form A, 60° angle
● Point angle: standard 118°
● Tolerance on body diameter: H9
● Tolerance on pilot dia: K12

DIN333A Center Drill
Drill Dia. Body Dia. Overall Length Milling Straight Flute Fully Ground Spiral Flute
HSS HSS CO5% HSS Left HSS HSS CO5%
0.50 3.15 25.00 660-2098 660-2111 660-2124 660-2137 660-2150
0.80 3.15 25.00 660-2099 660-2112 660-2125 660-2138 660-2151
1.00 3.15 31.50 660-2100 660-2113 660-2126 660-2139 660-2152
1.25 3.15 31.50 660-2101 660-2114 660-2127 660-2140 660-2153
1.60 4.00 35.50 660-2102 660-2115 660-2128 660-2141 660-2154
2.00 5.00 40.00 660-2103 660-2116 660-2129 660-2142 660-2155
2.50 6.30 45.00 660-2104 660-2117 660-2130 660-2143 660-2156
3.15 8.00 50.00 660-2105 660-2118 660-2131 660-2144 660-2157
4.00 10.00 56.00 660-2106 660-2119 660-2132 660-2145 660-2158
5.00 12.50 63.00 660-2107 660-2120 660-2133 660-2146 660-2159
6.30 16.00 71.00 660-2108 660-2121 660-2134 660-2147 660-2160
8.00 20.00 80.00 660-2109 660-2122 660-2135 660-2148 660-2161
10.00 25.00 100.00 660-2110 660-2123 660-2136 660-2149 660-2162
  • Previous:
  • Next:
    • Please contact us for further information. To assist you more effectively, Kindly provide the following details:
    ● Specific product models and the approximate quantities you require.
    ● Do you require OEM, OBM, ODM or neutral packing for your products?
    ● Your company name and contact information for prompt and accurate feedback.
    Additional, we invite you to request samples for quality testing.
